10x38mm 1000VDC Solar PV Fuse 1A, 2A ,3A ,4A,5A,6A,8A,10A,12A,15A,16A,20A,25A,30A,32A gPV
Yueqing Aidun Electrical produce “SOLARSON”brand SSPV series of 10x38mm, 1000Vdc PV fuses are for protecting and isolating photovoltaic strings. The fuses are specifically designed for use in PV systems with extreme ambient temperature, high cycling and low fault current conditions (reverse current, multi-array fault) string arrays. Four styles available for application flexibility.
Product description
□ According to IEC/EN60269-6 and UL248
□ Rated current：1A, 2A ,3A ,4A,5A,6A,8A,10A,12A,15A,16A,20A,25A,30A,32A
□ Rated voltage： 1000V DC
□Rated breaking capacity：DC 33kA
□ Operating class gPV and UL PV fuse link for Solar protection
Technical data
| Item | Product type | Size | Rated Voltage (V) | Rated Current(A) | Installation Method | Drawing No. |
| 001 | SSPV-30 | 10X38 | 1000VDC | 1,2,3,3.5,4,5,6,8,10,12,15, 16,20,25,30 | Cylindrical | Drawing 1 |
| 002 | SSPV-30B | 10X38 | 1000VDC | 1,2,3,3.5,4,5,6,8,10,12,15, 16,20,25,30 | Bolt fixing | Drawing 2 |
| 003 | SSPV-30P | 10X38 | 1000VDC | 1,2,3,3.5,4,5,6,8,10,12,15, 16,20,25,30 | PCB fixing | Drawing 3 |
| 004 | SSPV-30T | 10X38 | 1000VDC | 1,2,3,3.5,4,5,6,8,10,12,15, 16,20,25,30 | In-line with crimp terminal | Drawing 4 |
dimension
